REFLECTORS

LENA / LENINA

Ø111 mm LEDiL System Reflectors compatible with various sublenses LENA
and sockets.

LENA (www.ledil.com/lenafamily)
Compatibility:
• COBs with LES size up to 35 mm
• 3 party connectors from Ideal, Stucchi and Bender+Wirth,
rd
Typ.
Typ.
Name Beam type D H FWHM Typ. cd/lm
Eff.
LENA-M M 111 86 22 83 2.5
LENA-S S 111 86 11 85 7.6
LENA-SS SS 111 86 18 82 5
LENA-W W 111 86 46 82 1.3
LENA-WAS WAS 111 37 Asym 82 1.1
Additional accessories
LENA-LENS Diffuser lens
LENA-CLEAR-LENS Clear lens
LENINA (www.ledil.com/leninafamily)
Compatibility:
• COBs with LES size up to 35 mm
• 3 party connectors from Ideal, Stucchi and Bender+Wirth
rd
Typ.
Typ.
Name Beam type D H FWHM Typ. Eff. cd/lm
LENINA-M M 74 46 31 87 2.1 LENINA
LENINA-S S 74 46 19 88 4.5
LENINA-W W 74 46 53 87 1.1
LENINA-XW XW 74 46 73 89 0.6
Additional accessories
LENINA-DL Diffuser lens
LENINA-CL Clear lens
Base parts for LENA/LENINA
Name
LENA-ADAPTER-B Adapter ring for BJB interface
LENA-STD-BASE-CXA15
LENA-STD-BASE-CXA20
LENA-STD-BASE-CXA18
LENA-STD-BASE-CXA25
LENA-STD-BASE-CL340
LENA-STD-BASE-CLL030
LENA-STD-BASE-CLL040
LENA-STD-BASE-BXRA
LENA-STD-BASE-BASE-RS
LENA-STD-BASE-VERO13-18
LENA-STD-BASE-VERO29
LENA-STD-BASE-MEZ
LENA-STD-BASE-LUXEON-K
LENA-STD-BASE-COB204
LENA-STD-BASE-E30
FWHM angles, efficiencies and cd/lm values contained herein are typical values. Actual measured values
36 depend of the specific LED/optic combination. Go to www.ledil.com for LED specific values
and product datasheets.
