Page 85 - LED Modules

X-ML16300NCxx-NFSx757GR-12
PRODUCT PHOTO
PRODUCT PHOTO
SPECIFICATIONS X-MR0045NC-4080-NFSx757G-12
• Default driving method is constant current input
• CCT Range from 2000°K up to 6500°K
DATASHEET DATASHEET • Default driving method is constant current input
SPECIFICATIONS
• Luminous flux range from 516 lm to 1664 lm
• Efficacy of the module up to 183 lm/W
• CRI 80 is standart, CRI 70 and CRI 90 are available
• CCT Range from 2000°K up to 6500°K
• Outstanding system color tolerance MacAdam 3 over the full operating area
• Luminous flux range from 544 lm to 911 lm
• Efficacy of the module up to 157 lm/W
• Simple installation
• CRI 80 is standard, CRI 70 and CRI 90 are available
• Long life-time > 60,000 hours
• Outstanding system color tolerance MacAdam 3 over the full operating area
• 5 years guarantee at specified conditions
• Simple installation
• Long life-time > 60,000 hours
X-MR0045NC-4080-NFSx757G-12 X-ML16300NCxx-NFSx757GR-12 APPLICATIONS For your orders please call us:
• 5 years guarantee at specified conditions
+90 444 27 33
For your orders please call us:
+90 444 27 33
APPLICATIONS

Low Bay Lighting
Spotlight
Downlight
Interior Task Lighting Hospitality
Architecrual Lighting
Lighting
PHOTOMETRY

PHOTOMETRY

Common Characteristic [@Tj : 85°C]
LED Brand & Type X-MR00118NC-757xx-36 Electrical Connection
PCB Material Aluminium
Operating Temperature (°C) -25°C ~ 85°C Parallel 4
Storage Temperature (°C) -25°C ~ 85°C Series 9
Thermal Conductivity (W/m-K) 1,5 Total LED Quantity 36 W/O LENS
LED NF2L757GR-V1_R8000
Correlated Color Temperature (CCT) 4000K
Color Rendering Index (CRI) 80+
Module Operating Current (mA) 350 500 700
Branch Operating Current (mA) 87,5 125 175
Module Operating Voltage (V) 52 53 54 W/O LENS VANESSA-B-O VANESSA-B-S VANESSA-B-W
Module Power (W) 20,3 29,5 42
Module Light Output (lm) 3308,9 4454,5 5754
Module Efficiency (lm/W) 163 151 137 All Rights Reserved for TLS Technology Systems | Subject to Change with out Prior Notice.
LED NFSW757G-V2_R8000 All Rights Reserved for TLS Technology Systems | Subject to Change with out Prior Notice.
Akçaburgaz Mahallesi 3080. Sokak No:5 Esenyurt / İstanbul | www. tlsteknoloji.com | TEL: +90 444 27 33
Correlated Color Temperature (CCT) 4000K Akçaburgaz Mahallesi 3080. Sokak No:5 Esenyurt / İstanbul | www. tlsteknoloji.com | TEL: +90 444 27 33
Color Rendering Index (CRI) 80+
Module Operating Current (mA) 350 500 700
Branch Operating Current (mA) 87,5 125 175
Module Operating Voltage (V) 26 27 28
Module Power (W) 10 13,5 19,6
Module Light Output (lm) 1690 2146,5 2900,8
Module Efficiency (lm/W) 169 159 148

The table below shows how to Module Light Output changes depending on CCT (°K)
Lumen Output Multiplier
2000°K 2500°K 2700°K 3000°K 4000°K 5000°K 5000°K 5000°K 5700°K 5700°K 5700°K 6500°K 6500°K 6500°K
LED
(CRI 80) (CRI 80) (CRI 80) (CRI 80) (CRI 80) ( CRI 70) (CRI 80) (CRI 90) ( CRI 70) (CRI 80) (CRI 90) (CRI 70) (CRI 80) (CRI 90)
NF2x757GR-V1 0,610 0,730 0,910 0,950 0,961 1,010 0,994 0,811 1,010 0,996 0,805 1,005 1,010 0,800
NFSW757G-V2 0,683 0,820 0,960 0,990 1,000 1,060 1,060 0,894 1,060 1,060 0,880 1,050 1,016 0,880

Relative luminous intensity versus CCT (°K)

85
