X-ML16300NCxx-NFSx757GR-12
PRODUCT PHOTO
PRODUCT PHOTO
SPECIFICATIONS X-MR0045NC-4080-NFSx757G-12
• Default driving method is constant current input
• CCT Range from 2000°K up to 6500°K
DATASHEET DATASHEET • Default driving method is constant current input
SPECIFICATIONS
• Luminous flux range from 516 lm to 1664 lm
• Efficacy of the module up to 183 lm/W
• CRI 80 is standart, CRI 70 and CRI 90 are available
• CCT Range from 2000°K up to 6500°K
• Outstanding system color tolerance MacAdam 3 over the full operating area
• Luminous flux range from 544 lm to 911 lm
• Efficacy of the module up to 157 lm/W
• Simple installation
• CRI 80 is standard, CRI 70 and CRI 90 are available
• Long life-time > 60,000 hours
• Outstanding system color tolerance MacAdam 3 over the full operating area
• 5 years guarantee at specified conditions
• Simple installation
• Long life-time > 60,000 hours
X-MR0045NC-4080-NFSx757G-12 X-ML16300NCxx-NFSx757GR-12 APPLICATIONS For your orders please call us:
• 5 years guarantee at specified conditions
+90 444 27 33
For your orders please call us:
+90 444 27 33
APPLICATIONS

Low Bay Lighting
Spotlight
Downlight
Interior Task Lighting Hospitality
Architecrual Lighting
Lighting
PHOTOMETRY

PHOTOMETRY

Common Characteristic [@Tj : 85°C]
LED Brand & Type X-MR0045NC-757xx-15 Electrical Connection
PCB Material Aluminium
Operating Temperature (°C) -25°C ~ 85°C Parallel 5
Storage Temperature (°C) -25°C ~ 85°C Series 3
Thermal Conductivity (W/m-K) 1,5 Total LED Quantity 15 W/O LENS
LED NF2L757GR-V1_R8000
Correlated Color Temperature (CCT) 4000K
Color Rendering Index (CRI) 80+
Module Operating Current (mA) 350 500 700
Branch Operating Current (mA) 70 100 140
Module Operating Voltage (V) 16,8 17 18 W/O LENS VANESSA-B-O VANESSA-B-S VANESSA-B-W
Module Power (W) 5,88 8,5 12,6
Module Light Output (lm) 993,72 1351,5 1852,2
Module Efficiency (lm/W) 169 159 147 All Rights Reserved for TLS Technology Systems | Subject to Change with out Prior Notice.
All Rights Reserved for TLS Technology Systems | Subject to Change with out Prior Notice.
LED NFSW757G-V2_R8000 Akçaburgaz Mahallesi 3080. Sokak No:5 Esenyurt / İstanbul | www. tlsteknoloji.com | TEL: +90 444 27 33
Correlated Color Temperature (CCT) 4000K Akçaburgaz Mahallesi 3080. Sokak No:5 Esenyurt / İstanbul | www. tlsteknoloji.com | TEL: +90 444 27 33
Color Rendering Index (CRI) 80+
Module Operating Current (mA) 350 500 700
Branch Operating Current (mA) 70 100 140
Module Operating Voltage (V) 8,8 9 9,1
Module Power (W) 3,08 4,5 6,4
Module Light Output (lm) 539 742,5 992
Module Efficiency (lm/W) 175 165 155

The table below shows how to Module Light Output changes depending on CCT (°K)
Lumen Output Multiplier
2000°K 2500°K 2700°K 3000°K 4000°K 5000°K 5000°K 5000°K 5700°K 5700°K 5700°K 6500°K 6500°K 6500°K
LED
(CRI 80) (CRI 80) (CRI 80) (CRI 80) (CRI 80) ( CRI 70) (CRI 80) (CRI 90) ( CRI 70) (CRI 80) (CRI 90) (CRI 70) (CRI 80) (CRI 90)
NF2x757GR-V1 0,610 0,730 0,910 0,950 0,961 1,010 0,994 0,811 1,010 0,996 0,805 1,005 1,010 0,800
NFSW757G-V2 0,683 0,820 0,960 0,990 1,000 1,060 1,060 0,894 1,060 1,060 0,880 1,050 1,016 0,880

Relative luminous intensity versus CCT (°K)
